Hycat™ 3100S – Liquid Epoxy Catalyst

Hycat™ 3100S replaces Hycat™ 3000S as our flagship anhydride catalyst used to accelerate the reaction of epoxy resins with various anhydrides including MTHPA, MHHPA, NMA, PA and more. Hycat™ 3100S will also promote the reaction of epoxides and carboxylic acids, however DTCS suggests the use of Hycat™ 2000S or Hycat™ OA for that type of system. Hycat™ 3100S is especially effective in curing epoxy-anhydride systems at low to moderate temperatures. Low onset temperatures allow formulators to gel and cure systems using less energy. Low peak temperatures and a more even exothermic distribution of the catalyzed reaction produces consistently uniform cures, free from voids and cracks.  This is particularly useful in the curing of composites and thick parts where materials that have been wet out with low viscosity materials require a quick gel but excessive exotherms can lead to hidden defects in the final cure. The unique low temperature characteristics and curing properties of Hycat™ 3100S have allowed some formulators to significantly reduce or even eliminate high temperature post cure cycles.  Thus usage of curing equipment can be optimized for less energy consumption and increased capacity.

Get it going with Hycat™!

Hycat™ 3100S can be used as a co-catalyst to take full advantage of it its low onset capabilities, allowing formulators to reconsider the use of anhydrides for their unique physical properties where previously, high initial temperature requirements coupled with excessively rapid cures using amines or imidazoles may have been inhibitive.

Hycat™ 3100S is a liquid so it is easy to handle, easy to load, easy to adjust and is readily cleaned up with typical organic solvents. Hycat™ 3100S accelerates materials with monomeric, dimeric or polymeric functional groups and will perform very well in the presence of a number of popular toughening agents. This provides formulators with great flexibility to meet desired cure temperatures, cure cycles, pot life, glass transition temperature and other mechanical properties. These attributes make Hycat™ 3100S ideal for use in composite processes including, filament windings, pultrusion, RTM, SMC and numerous other areas of application.

Typical catalyst loadings range from 1 to 5 phr however higher or lower concentrations can be used depending on the formulation and desired end result. Cured products will have a light green tint, the intensity of which is determined by catalyst loading.

Hycat™ 3100S is REACH and RoHS compliant and is manufactured under ISO 9002 quality assurance control standards. Free evaluation samples are available via our Sample Request page or by email at This email address is being protected from spambots. You need JavaScript enabled to view it.


Typical Physical PropertiesQuantities Available

Physical State

Liquid



Packaging (HDPE All)

Net Wt

Appearance (color)

Emerald Green



200L Drums

200 Kgs (440 Lbs)

Viscosity (cP)

300 - 500 @ 25o C



50L   Drums

50 Kgs    (110 Lbs)

Density

1.0 @ 25o C



20L   Jerricans

20 Kgs    (44 Lbs)

Shelf Life

2 years



4L     Bottles

4 Kgs      (8.8 Lbs)



Recommended Uses:

Hycat™ 3100S is recommended for use in epoxy/anhydride formulations.  Most epoxy resins, including Aliphatic, Cycloaliphatic, Phenol-Type Di-and Tri-Glycidyl Ethers, Novolacs and many other epoxy resins will benefit using Hycat™ 3100S.

Hycat™ 3100S will also accelerate the reaction of other small ring compounds such as aziridines, oxetanes and imides and promote the reaction of an epoxide with a carboxylic acid however Hycat™ 2000S and Hycat™ OA are recommended for acid systems.



Typical commercial applications include:

Filament Winding

Composites

Pultrusion

Potting & Encapsulation

Resin Infusion

Spray Layup

Sheet Moulding Composites

Polymer Coatings

Wet Layup



Additional Information:

Hycat™ 3100S loadings typically range from 1 to 5 phr (parts per hundred epoxy resin) however higher or lower concentrations can be used depending on the formulation and desired end result. Cured products will have a light green tint, the intensity of which is determined by catalyst loading.

DTCS recommends that for evaluations conducted with Hycat™ 3100S that Hycat™ SM-3 and          Hycat™ AC-4 also be evaluated. All of these products perform in a similar manner but depending upon the formulation, each has unique synergistic differences that could be advantageous.

Hycat™ 3100S is based on an activated (DTCS Proprietary Process) oxo-centered-trinuclear Chromium +3 complex. Chromium +3 compounds (aka trivalent chromium), are generally considered to be non-toxic by the EPA and are not to be confused with hazardous Chromium +6 compounds (aka Hexavalent Chromium). In fact Chromium +3 compounds are sold as over the counter dietary supplements such as chromium picolinate and Chromium +3 is considered to be an essential trace element for the human metabolism. For more toxicological information on Chromium +3 please see the US Dept of Health & Human Services, National Institute of Health website at https://ods.od.nih.gov/factsheets/Chromium-HealthProfessional/



HycatTM 3100S – Comparative Data



The following tables and graphs provide comparative DSC and viscosity data for basic epoxy formulations catalyzed by Hycat™ 3100S and other commonly used epoxy catalysts at approximately 2% catalyst loading by weight (~ 4 phr).



Bisphenol A Diglycidyl Ether & Methyltetrahydrophthalic Anhydride



TABLE 3S-1

Resin System

phr

DSC Analysis 25oC – 250oC @ 10oC/min

Time to 100k cP (3)

Onset oC

Peak oC

Endset oC

Energy J/g

Tg oC (4)

80oC (min)

25oC (hrs)

BADGE (1)

MTHPA (2)

Hycat™ 3100S

100:86:4

71

132

185

272

115

21

8.7



(1) Bisphenol A Diglycidyl Ether, Epon 828 (Momentive Specialty Chemicals)

(2) Methyltetrahyrdophthalic Anhydride, Lindride 2 (Lindau Chemicals)

(3) 15g mass by Brookfield LVDV-II & Thermosel module; Time to 100,000 cP reported at set temperature

(4) 15g mass cured 2hrs @ 100oC + 2hrs @ 150oC; final thickness 5.5mm; Double DSC scan,

      50oC-200oC @ 10oC/min; Midpoint Method; *Note: Higher Tg’s can be realized with formula and cure optimization

(5) ND – No data, test not performed





GRAPH 3S-1



GRAPH 3S-2



GRAPH 3S-3



GRAPH 3S-4





GRAPH 3S-5



GRAPH 3S-6



GRAPH 3S-7





GRAPH 3S-8



GRAPH 3S-9



Bisphenol A Diglycidyl Ether & Methylhexahydrophthalic Anhydride



TABLE 3S-2

Resin System

phr

DSC Analysis 25oC – 250oC @ 10oC/min

Time to 100k cP (3)

Onset oC

Peak oC

Endset oC

Energy J/g

Tg oC (4)

80oC (min)

25oC (hrs)

BADGE (1)

MHHPA (2)

Hycat™ 3100S

100:89:4

74

136

185

221

139

26

8.4



(1) Bisphenol A Diglycidyl Ether, Epon 828 (Momentive Specialty Chemicals)

(2) Methylhexahyrdophthalic Anhydride, Lindride 52D (Lindau Chemicals)

(3) 15g mass by Brookfield LVDV-II & Thermosel module; Time to 100,000 cP reported at set temperature

(4) 15g mass cured 2hrs @ 100oC + 2hrs @ 150oC; final thickness 5.5mm; Double DSC scan,

      50oC-200oC @ 10oC/min; Midpoint Method; *Note: Higher Tg’s can be realized with formula and cure optimization





GRAPH 3S-10



GRAPH 3S-11



GRAPH 3S-12



GRAPH 3S-13



GRAPH 3S-14



GRAPH 3S-15



GRAPH 3S-16



GRAPH 3S-17



GRAPH 3S-18





Cycloaliphatic Epoxide & Methyltetrahydrophthalic Anhydride

TABLE 3S-3

Resin System

phr

DSC Analysis 25oC – 250oC @ 10oC/min

Time to 100k cP (3)

Onset oC

Peak oC

Endset oC

Energy J/g

Tg oC (4)

80oC (min)

25oC (hrs)

Cycloaliphatic (1)

MTHPA (2)

Hycat™ 3100S

100:116:4

105

139

170

249

148

34

32.9



(1) Cycloaliphatic Epoxide, Lindoxy 190 (Lindau Chemicals)

(2) Methyltetrahyrdophthalic Anhydride, Lindride 2 (Lindau Chemicals)

(3) 15g mass by Brookfield LVDV-II & Thermosel module; Time to 100,000 cP reported at set temperature

(4) 15g mass cured 2hrs @ 100oC + 2hrs @ 150oC; final thickness 5.5mm; Double DSC scan,

      50oC-200oC @ 10oC/min; Midpoint Method; *Note: Higher Tg’s can be realized with formula and cure optimization



GRAPH 3S-19



GRAPH 3S-20



GRAPH 3S-21



GRAPH 3S-22



GRAPH 3S-23



GRAPH 3S-24



GRAPH 3S-25



GRAPH 3S-26





Cycloaliphatic Epoxide & Methylhexahydrophthalic Anhydride

TABLE 3S-4

Resin System

phr

DSC Analysis 25oC – 250oC @ 10oC/min

Time to 100k cP (3)

Onset oC

Peak oC

Endset oC

Energy J/g

Tg oC (4)

80oC (min)

25oC (hrs)

Cycloaliphatic (1)

MHHPA (2)

Hycat™ 3100S

100:120:4

101

139

174

231

163

33

34



(1) Cycloaliphatic Epoxide, Lindoxy 190 (Lindau Chemicals)

(2) Methylhexahyrdophthalic Anhydride, Lindride 52D (Lindau Chemicals)

(3) 15g mass by Brookfield LVDV-II & Thermosel module; Time to 100,000 cP reported at set temperature

(4) 15g mass cured 2hrs @ 100oC + 2hrs @ 150oC; final thickness 5.5mm; Double DSC scan,

      50oC-200oC @ 10oC/min; Midpoint Method; *Note: Higher Tg’s can be realized with formula and cure optimization



GRAPH 3S-27



GRAPH 3S-28



GRAPH 3S-29



GRAPH 3S-30



GRAPH 3S-31





GRAPH 3S-32



GRAPH 3S-33
